TURN HEADS WITH THE
Sleek Tablet-Like Aesthetic with inclusive CMS Software
Our Freestanding ASL Series Displays are proven to be real attention grabbers and stand out in a busy commercial environment providing businesses a fresh approach to digital signage… an ‘Out of the Box, Fully Inclusive’ approach which enables businesses to control and manage costs and deployment in a more effective way.
With our latest Android powered Freestanding screens, the functionality has increased delivering even more benefits for your business
The standard white model is the clean, modern look – but we can also offer a black version on request.
Download Product Sheet
See Product Specs
High Impact Digital Signage
Lockable Compartment
Tablet-like Aesthetic
PRODUCT HIGHLIGHTS
Packed with even more power & functionality these displays will not only look great but deliver stunning performance.
LIGHTWEIGHT AND EASY TO MOVE
Recessed rear handles, integrated castors and a lightweight frame make the Freestanding ASL displays the perfect portable solution. Once in place, simply retract the in-built feet!
INCLUSIVE TOPAZ CMS SOFTWARE
The inclusive, in-built, high-powered TOPAZ CMS Digital Signage Software makes managing and updating your displays easy!
LOCK PROTECTED COMPARTMENT
We understand you may wish to run the display using your own media player or PC, so have built a lockable compartment in the rear of the unit.
TOUGHENED TEMPERED GLASS
The ASL Series Screens have integrated Wi-Fi enabling you to connect seamlessly to the TOPAZ™ CMS system. This ensures you can update your message from any PC in the world!
IN-BUILT ANDROID MEDIA PLAYER
As well as being built on the Android 7.1 Operating System the ASL range all feature a more powerful CPU and graphics processor enabling you to handle more demanding graphics in turn delivering more immersive and attention grabbing content!
24/7 USAGE
Using commercial grade LCD panels, LED backlights and internal components, the Freestanding ASL Displays are designed for 24/7 usage.
TOPAZ FREESTANDING ASL SPECIFICATIONS
| SIZE | 50" | 55" | 65" |
|---|---|---|---|
| Unit Size (hxwxd mm) | 1843.1 x 665.6 x 41.2 | 1911.5 x 744 x 41.2 | 883.6 x 2018 x 92.8 |
| Unit Weight (kg) | 48 | 69.5 | 92 |
| Display Area (mm) | 603 x 1072 | 681.4 x 1210.6 | 802.5 x 1427.5 |
| Footprint (mm) | 665.6 x 500 | 744 x 500 | 634.87 x 883.6 |
| Speaker Type | 10W, 4Ω (x2) | 10W, 4Ω (x2) | 10W, 4Ω (x2) |
| Resolution | 1080 x 1920 | 1080 x 1920 | 2160 x 3840 |
| Aspect Ratio | 9:16 | 9:16 | 9:16 |
| Brightness (cd/m2) | 450 | 450 | 450 |
| Contrast ratio | 5000:1 | 5000:1 | 1200:1 |
| Colour | 16.7M | 16.7M | 16.7M |
| Viewing Angle | 178° | 178° | 178° |
| Input Voltage | AC110-240V (50Hz-60Hz) | AC110-240V (50Hz-60Hz) | AC110-240V (50Hz-60Hz) |
| Working Temperature | 0ºC to 40ºC | 0ºC to 50ºC | 0ºC to 50ºC |
| Display Size | 50" | 55" | 65" |
|---|---|---|---|
| Video | HDMI VGA | HDMI VGA | HDMI VGA |
| Audio | Audio Socket (3.5mm) | Audio Socket (3.5mm) | Audio Socket (3.5mm) |
| SIZE | 50" | 55" | 65" |
|---|---|---|---|
| Media Resolution | 1080 x 1920 | 1080 x 1920 | 3840 x 2160 |
| Internal Memory | 8GB | 8GB | 8GB |
| CPU | Quad-Core ARM Cortex A17, 1.6GHz | Quad-Core ARM Cortex A17, 1.6GHz | RK3399 Hexa-Core 1.8GHz |
| GPU | Quad-Core ARM Mali-T764 | Quad-Core ARM Mali-T764 | - |
| RAM | 2GB DDR3 | 2GB DDR3 | 4GB DDR3 |
| ROM | 8GB eMMC | 8GB eMMC | 32GB eMMC FLASH |
| USB | 1 x USB (OTG/HOST), 1 x USB (HOST) | 1 x USB (OTG/HOST), 1 x USB (HOST) | USB 3.0 x 2, USB 2.0 x3 |
| LAN | 100/1000M Ethernet | 100/1000M Ethernet | 100/1000M Ethernet |
| WiFi | 802.11b/g/n/ac | 802.11b/g/n/ac | 802.11b/g/n/ac |
| OS | Android 7.1 | Android 7.1 | Android 7.1 |
| Graphic Engine | OpenGL ES 1.1/2.0/3.0/3.1, OpenCL 1.1, Renderscript, Direct3D 11.1 | OpenGL ES 1.1/2.0/3.0/3.1, OpenCL 1.1, Renderscript, Direct3D 11.1 | ARM Mali-T864 Quad-Core |
| Software | TOPAZ CMS | TOPAZ CMS | TOPAZ CMS |
| Media Formats | Video: MPG4 Image: JPG | Video: MPG4 Image: JPG | Video: MPG4 Image: JPG |
50″
55″
TOPAZ Content Management System (CMS)
- Manage your content through our cloud based content management system from anywhere in the world.
- User control enables you to manage your users and control who in your organisation has access to update specific areas.
- Clients are issued with a username and password for our secure web portal, where they can upload their content at the click of a button which is stored on our secure server.
- Utilize zoned templates to present your videos, images, scrolling text messages, web pages and live RSS feeds.
- Create multiple playlists to determine exactly when the relevant content is displayed.
- Update your screens individually or in groups, manually or automatically depending on your requirements.
Launch CMS
Create custom layouts –
Choose from one of the pre-designed templates or create your own layouts using zones such as video, images, text, web pages, weather and more!
This allows you to deliver targeted content and display your messages exactly how you want to!
Populate your layout –
Upload your images and videos and simply drag and drop into your created zones to create your playlist!
Text zones can also be populated through linking to external RSS feeds or custom messaging – ensuring your messages are targeted as well as informative!
Update your screens from anywhere –
Content can be uploaded and managed from anywhere in the world via our secure web portal. Simply log in, upload your images and videos to our secure server and send them directly to your screens.
